MonoRail
- Super Slim liner with power track
- Greatly extends the length of a run with a single power point
- Fixtures snaps onto power track with no breaks in light output
- To be used with constant voltage DC 24V driver
- Dimmable with available accessories
Easy connection
Rail power track- supply power to other electrics
- Voltage : DC 24V
- Operating temperature : 0~45 °C
- Lamp life : 40,000hr / 70%
- Available color : 2700K, 3000K, 3500K, 4000K, 6000K
- Color rendering : Ra>80
- Energy efficiency : 75lm/W
- Degree of protection IP20
Max. connection
- MonoRail :200W in one row (Single powerfeed)
- LED Driver
| Model Name | 24V/75W | 24V/180W/th> |
|---|---|---|
| DVR1A4B24M | 57 | 138 |
| DVR3A4B24M | 20 | 48 |
| Model Name | Power Input | Lamp Power(W) | A(mm) | A'(mm) | B(mm) | B'(mm) | C(mm) | C'(mm) | D(mm) | E(mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| DVR1A4B24M | DC 24 | 1.3 | 95 | 121 | 15.3 | 17 | 12.3 | 16.6 | 15.6 | 14.6 |
| DVR3A4B24M | DC 24 | 3.7 | 286 | 312 | 15.3 | 17 | 12.3 | 16.6 | 15.6 | 14.6 |
| Rail |  |
DVR1A4B24M DVR3A4B24M |
Monorail 1W fixture Monorail 3W fixture |
|---|---|---|---|
| Rail |  |
DVR-Rail | Power supply track |
| Power feed |
 |
DVRPC | Power supply cable to the Rail 2500mm |
| Connect cable |
 |
DVRPTC DVRPTC1 DVRPTC2 DVRPTC4 DVRPTC6 |
150mm(6inch) 300mm(1feet) 600mm(1feet) 1200mm(4feet) 1800mm(6feet) |
| Connect cable |
 |
DVRPTC-HDV1 VDRPTC-NDV2 |
300mm(1feet) 600mm (2feet) between Rail and Diva2 |
| Connect cable |
 |
DVRPTC-HDV1 VDRPTC-HDV2 |
300mm(1feet) 600mm (2feet) between Rail and Diva2 HO&Dual |
| Sidefeed |  |
DVR1A4B24M/S | Sidefeed for seamless extension(1W) |
| LED driver |
 |
FCL75-24V/T FCL180-24V/T |
75W 24V 180W 24V with 6way distributor, with power cord(1800mm) |
| Mounting bracket |
 |
DVR-BRACKET1 | |
| End cap |
 |
DVR-CAP |
